Mylch Alu-Clad Timber EX Systems
Engineering nature to perfection
Mylch EX Series is born from a philosophy of architectural dualism, establishing a seamless dialogue between structural skin and interior sanctuary. Engineered as a hybrid structural platform, the series utilizes an advanced external aluminum shield that acts as a definitive thermal and physical armor against climatic extremes. Beneath this impervious defense, the system reveals an interior curated entirely in premium solid timber—transforming the window frame into an organic sculptural element that grounds modern spaces in absolute silence and tectonic warmth. This is not merely a combination of materials, but an uncompromised structural synthesis designed for landmark residential architecture where high-performance engineering elevates luxury into an enduring heritage.
Alu-Clad Timber EX88 Series: Nature Meets Engineering
Mylch EX88 Series represents the ultimate integration of structural rigidity and natural aesthetics. Evolving from decades of continuous structural adaptation across renowned German and Italian engineering frameworks, the EX88 platform has matured into a definitive architectural solution. Engineered with an exterior heavy-duty, weather-resistant aluminum shield, the system guarantees zero maintenance and permanent protection against severe weather and UV radiation. Inside, the platform is defined by premium, sustainably sourced solid timber strips, acting as a natural acoustic and thermal barrier that significantly reduces energy consumption. Fully compliant with rigorous North American standards, the EX88 profiles are tailored for premium global envelopes. To align with bespoke architectural palettes, our interior wood profiles are available in a diverse selection of high-end timber species—including Oak, Larch, and Pine—offering a wide array of customized color and texture finishes that elevate luxury residential design.
Craft for living
Engineered for those who demand the warmth of wood and the durability of aluminum.
Aluminum-Clad Wood System
EX 88 - Enhanced Thermal Performance
-
Thermal Insulation : Uf < 1.8 W/m²·K
-
Acoustic Rating : 38 dB
-
Air Permeability : Class 8
-
Watertightness : 500 Pa
-
Profile technology: 4-chamber continuous insulation, 28mm multi-cavity thermal break.
-
Sealing standard: European standard hard-soft co-extruded EPDM gaskets with moisture-expansion core.
EX 95- Structural Truss Technology
-
Thermal Insulation : Class 9 (Depending on Glazing)
-
Acoustic Rating : 38 dB (Depending on Glazing)
-
Air Permeability : Class 8
-
Watertightness : 600 Pa
-
Profile technology: Application of structural truss technology with 34mm Ensinger multi-cavity thermal break and LEF low-emission technology.
-
Sealing standard: European standard hard-soft co-extruded EPDM gaskets combined with high-performance PU wrapped seals.
-
Craftsmanship & Hardware: Mortise-tenon corner joinery with glueless clip connection, equipped with Roto 13 series heavy-duty hardware (130KG) and HOPPE anti-pry handle.
